Suitable wire range: AWG16–AWG30
Cutting length: 10–600mm; Customization: Max. 1500mm
Stripping length: 0–15mm
Cutting Accuracy: ±(0.2%+1)mm
Twisting length: 3–15mm
Tinning length: 1–15mm
Capacity: AWG22–AWG30, can process 1–8 wires at the same time (the same AWG#), the production capacity is about 9000–11000 pieces/hour; AWG20–AWG18, 1–5 wires, about 4000–5500 pieces/hour; AWG18–AWG16, 1–3 wires, about 2700–3000 wires/hour
Power supply: 220VAC single phase; 50–60Hz
Dimensions: 1210×770×1370mm (L×W×H)
Net weight: 400kg
Air supply: 0.5–0.7Mpa (5–7KG/m³)
