Frequency range: 1.6 MHz … 30 MHz
Usable frequency range (typical): < 1.0 MHz … > 50 MHz
Insertion loss: 8 dB ± 0.2 dB
Frequency ripple (flatness): < 0.2 dB
Symmetrical impedance (output): 100 Ω
Unsymmetrical impedance (input): 50 Ω
Max. input power: 200 mW
VSWR: < 1.1 :1 @ 30 MHz
Proof voltage against housing: > 500 V DC
Housing material: Aluminium
Dimensions (L × W × H): 125 mm × 104 mm × 50 mm
Weight: approx. 270 g
Unsymmetrical connector: BNC jack 50 Ω
Symmetrical terminals: 4 mm safety laboratory jack
Terminal spacing (on symmetrical side): 19 mm
