Nominal frequency range: 80 MHz ... 3 GHz
Usable frequency range: 70 MHz ... 4 GHz
Isotropic gain: 9 ± 3 dBi
Antenna factor: 2 ... 32 dB/m
Nominal impedance: 50 Ω
Standing Wave Ratio (SWR) typical: 1.6 (f < 3 GHz)
Front to Back Ratio: 8 - 22 dB
Cross polarisation: >30 dB
3 dB beam width typ. (E-Plane): 60° - 75°
3 dB beam width typ. (H-Plane): 50° - 65°
Max. input power (N-Connector): 1.5 kW (intermitt.), 1 kW (const.)
Max. input power (7/16-Connector): 3 kW (intermitt.), 2 kW (const.)
Mounting tube: Ø = 22 mm
Width × length × height while set up in vertical polarisation: 1480 × 1480 × 1340 mm
Weight: 8.1 kg
