Frequency range (nominal): 5 Hz – 1 MHz
Gain (without load): 26 dB ±3 dB
AC Output current: 28 Aₘₛ
(50% duty cycle up to 5 min.)
AC Continuous operating current: 14 Aₘₛ
AC Impedance of load min.: 0.25 Ω
Max. output voltage: 60 Vₚₑₐₖ @ 5 Hz – 250 kHz
Linearly decreasing to 30 Vₚₑₐₖ @ 1 MHz
Max. output current: 40 Aₚₑₐₖ
Typical input impedance: 1 kΩ
Input jack: BNC (isolated)
Output Connectors: Wing terminals
Ambient temperature: –10°C / +40°C
Power supply: 230 VAC Power-Con
Current consumption: <16 Aₘₛ
Material of the housing: Aluminium
Housing dimensions (W × D × H): 448 × 410 × 268 mm
Overall dimensions: 448 × 473 × 280 mm
Weight: ca. 40 kg
