Frequency range: 1.6 MHz … 30 MHz
Longitudinal Conversion Loss (LCL): > 55 dB
Maximum operating current: 16 A
Maximum operating voltage: 250 VAC @ 50/60 Hz
Differential mode (line‑to‑line) impedance: 100 Ω ±10 Ω
Differential mode phase angle: 0° ±25°
Common mode impedance: 25 Ω ±3 Ω
Phase angle: 0° ±25°
Measurement port: BNC jack, 50 Ω
Voltage division factor EuT – measurement port:: 0 dB ±1 dB
Isolation CS – measurement port: > 55 dB
Insertion loss EuT – CS: < 3 dB
Proof voltage L/N to housing: > 1000 VDC
Housing material: Aluminium
Dimensions: 225 x 120 x 105 mm
Weight: ≈ 1300 g
Connectors for EuT, CS: 4 mm safety laboratory jacks
Ground connectors: bottom of case, 4 mm laboratory jack and M4 bolt and nut
