Number of turns (per Coil): 9
Maximum coil current: 55 A, 5 min.
Nominal continuous coil current: 33 A
Coil spacing for best field uniformity: 132 mm
Coil spacing for high field strengths (all following values refer to 116 mm coil distance): 116 mm
Maximum magnetic field strength: 3053 A/m, 5 min.
Nominal continuous magnetic field strength: 1832 A/m
Magnetic field strength @ 1 A Coil Current: 55.52 A/m
Current required for 1 A/m: 18 mA
Conversion Current–Fieldstrength (Coil factor): 154.89 dBµA/m / 34.9 dB/m
Coil diameter: 232 mm
Mechanical dimensions: 0.20 m × 0.25 m × 0.39 m
Max. cubical shaped DuT: 11.3 × 11.3 × 11.3 cm
Terminals: 4 mm banana jacks and 7 mm screw terminals
Usable frequency range: DC – 2.5 MHz
Inductance (per coil): 36 µH
Inductance (pair of coils): 80 µH
Resistance (per coil): 33 mΩ
Coil capacitance (pair of coils): 24 pF
Resonance frequency (pair of coils): > 3.5 MHz
Weight: 4.9 kg
