Number of turns: 225
Wire diameter: 2 mm
Maximum coil current: 20 A
Max. magnetic field strength at 50 mm spacing: 17 kA/m
Magnetic field strength at 1 A coil current in 50 mm distance: 858.2 A/m
Required current for 1000 A/m in 50 mm distance: 1.165 A
Magnetic flux density at 1 A coil current in 50 mm distance: 1.078 mT
Conversion current–magnetic field strength: 180.66 dBpT / 58.67 dB/m
Mechanical dimensions: 190 × 190 × 290 mm
Terminals: 4 mm Banana
Length of connection cable: 3 m
Usable frequency range: 0 – 20 (50) kHz
Weight: 5.3 kg
