Tension Range: 5 - 50 cN
Measuring Head Width*: 63 mm
SCHMIDT Calibration Material**: PA: 0.12 mm Ø
Calibration: According to SCHMIDT factory procedure
Accuracy: ±1 % full scale or ±1 graduation on scale
Scale diameter: 54 mm
Temperature range: 10 – 45 ºC
Air humidity: 85 % RH, max.
Housing material: Plastic (POM)
Dimensions: See dimensions
Weight, net (gross): Approx. 220 g (620 g)
Other tension ranges available on request.
Other units of measure available, such as g.
* Width of filament guide
** Suitable for 95 % of applications – PA = Polyamide Monofilament
Delivery Includes: carrying case, operating instruction in German or English (as requested), Certificate of Compliance with the order 2.1 free of charge
