- Power rating: 1 kVA
- Input
+ Input Voltage Range: (110-300)VAC
+ Frequency Range: 40-70 Hz
+ Input Power Factor: ≥0.98
- Battery and charger
+ Tegangan Pengenal Baterai: 36 V
+ Type: Maintenance-free Sealed Lead-acid UPS Batteries
+ Number of Internal Battery: 2PCS
+ Recharge Current: 6 A
- Output
+ Nominal Output Voltage: 220*(1±2%)VAC
+ Frequency Range: sync with line of +/-4Hz(Line mode) 50±0.05Hz (Battery mode)
+ Output Power Factor: 0.9@30°C and 0.8@40°C
+ Overload capacity: 105%-150%，47s-25s；150%-200%，25s-300ms；>200%，200ms (0.8PF)
+ Outlet: IEC C13*6 pcs - Waktu Transfer + Battery Mode<-->Inverter Mode: 0ms
+ Inverter Mode<-->Bypass Mode: 4ms (typical)
- Backup time (80% load, 0.8PF): depends on customer configuration
- Indicator:
+ LED: Load, battery capacity, UPS working mode
- Alarm
+ Battery Discharge: Battery full: 1buzzing/4s; Battery empty: 1buzzing/1s
+ Alarm UPS: Buzzing continue
- Auto restart: Auto restart while mains recover
- Interface
+ USB: Monitoring
+ Optional Parts: NMC Card, Modbus Card, Relay Card
- Environment
+ Temperature: 0°C-40°C
+ Humidity: 0-95%, non-condensing
- Net Weight
+ UPS: 7.2 kg
+ EBM: 20.0 kg
- Dimension (W*D*H)
+ UPS: 438*420*87 mm
+ EBM: 438*420*87 mm
