The output voltage:
1V～4000V adjustable (open circuit)
0.5V～2000V adjustable (50Ω load)
Pulse polarity: Positive, negative, positive and negative alternating
Square Wave
Pulse Width: 50～1000ns adjustable (50ns step)
Rise time: ＜1ns
Output Impedance: 50Ω
Pulse repetition mode
Single trigger: Manual button
External trigger: TTL level 100Hz (MAX)
Internal trigger: 1～100Hz
Phase injection method: asynchronous, Synchronous injection phase 0～359°
Coupling and Decoupling Networks: Built-in single-phase three-wire coupling/decoupling network
Coupling and decoupling network capacity
AC: AC230V/16A
Frequency: 50/60Hz
DC: DC230V/16A
Instrument working power supply: AC220V 50/60Hz
Test method: Phase-to-phase differential mode testing
Common mode test of phase and ground
Dimensions (W x D x H): 430mm×400mm×250mm
Weight: About 20kg
