Performance
1. Integrated design
2. Fast test speed. Using ARM high-speed acquisition system can collect signal changes in real time and can accurately position the steel.
3. 3.5inch Big Colorful Display Screen, Iphone type Design for simple operation
4. Steel intensive scanning capabilities with the Intensive steel scanning module.
5. Based on the instrument scanning speed to amend the protective layer thickness.
6. Display test information real-time. Interpret and display the test data intelligently to avoid man-made errors
7. Grid and section scan mode. Instrument can display steel-bar distribution and scan steel-bar without concrete size limited.
8. With Built-in high-capacity Lithium battery. Instrument can be used up to 28 hours
9. Powerful data process and analysis software in Windows. Test data can be export to word or excel easily.
Technical Data
Applicable steel-bar diameter: 6mm~50mm
Tested range of concrete backing thickness:
+ Low range：6mm~90mm；
+ High range：7mm~190mm
Permissible error
+ Low range
6~59: ±1
60~69: ±2
70~90: ±4
+ High range
7~79: ±1
80~119: ±2
120~190: ±4
Tested range of steel-bar diameter: 6mm~50mm
Permissible error of steel-bar diameter test: ±1 grade
Applicable environmental:
+ Temperature: -10℃~＋40℃; Dampness: <90%RH
+ EMI: no Strong electromagnetic field
