Optical Geometry: Reflectance: d/8 (SCI⪰ Include UV/Exclude UV)
Transmittance: d/0 (SCI⪰ Include UV/Exclude UV)
Conforms to CIE No.15, GB/T 3978, GB 2893, GB/T 18833, ISO7724/1, ASTM E1164, DIN5033 Teil7
Specular Component: Reflectance: SCI&SCE
Transmittance: SCI&SCE
Integrating Sphere Size: Φ 154mm
Sensor: 256 Image Element Double Array CMOS Image Sensor
Light Source Device: 360nm-780nm Combined LED Lamp, 400nm cut-off, UV Lamp
Illuminants: D65, A, C, UV, D50, D55, D75, F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12
Spectrophotometric Mode: Concave Grating
Observer Angle: 2°&10°
Repeatability: Spectral reflectance: Φ25.4mm/SCI, Standard deviation within 0.05% (400 nm to 700 nm: within 0.04%)
Chromaticity value: Φ25.4mm/SCI, Standard deviation within ΔE*ab 0.02 (When a white calibration plate is measured 30 times at 5 second intervals after white calibration)
Spectral Transmittance: Φ25.4mm/SCI, Standard deviation within 0.05% (400 nm to 700 nm: within 0.04%)
Chromaticity value: Φ25.4mm/SCI, Standard deviation within ΔE*ab 0.03 (When a white calibration plate is measured 30 times at 5 second intervals after white calibration)
Inter-instrument Error: Φ25.4mm/SCI, Within ΔE*ab 0.15 (Average for 12 BCRA Series II color tiles)
Wavelength Range: 360-780nm
Wavelength Pitch: 10nm
Semiband Width: 10nm
Reflectance Range: 0~200%
Measuring Aperture: Reflective: Φ30mm/Φ25.4mm, Φ18mm/Φ15mm, Φ10mm/Φ8mm; Φ6mm/Φ4mm;
Transmissive: Φ30mm/Φ25.4mm;
Color Space: CIE Lab, XYZ, Yxy, LCh, CIE LUV, Hunter LAB, Munsell, s-RGB, HunterLab, DIN, βxy
Color Difference Formula: ΔE*ab, ΔE*uv, ΔE*94, ΔE*cmc(2:1), ΔE*cmc(1:1), ΔE*00v, ΔE(Hunter), DIN ΔE99
Displayed Data: Spectrogram/Values, Chromaticity Values, Color Difference Values/Graph, Pass/Fail Result, Color Offset
Colorimetric Index: WI (ASTM E313, CIE/ISO, AATCC, Hunter), YI (ASTM D1925, ASTM 313), TI (ASTM E313, CIE/ISO), MI (Metamerism Index), Staining Fastness, Color Fastness, Color Strength, Opacity, Gardner Index, Pt-Co Index, 555 Index,
PC Terminal Software: SQCX
Data Storage Capacity: Standard: 5000 Pcs; Sample: 40000 Pcs.
(One PCS can include both SCI and SCE)
Data Port: USB & Bluetooth
Locating Method: Camera Locating
Measurement Mode: Single Measurement & Average Measurement
Screen: 7" TFT Capacitive Screen-touch Display
Light Source Device Life: 5 years, more than 3 million times measurements.
Power Supply: DC 24V, 2A Power Adapter
Size: 370×300×200mm
Weight: 16kg
Language: English & Chinese
Working Environment: Temperature: 0~40℃; Humidity: 0~85% (No Condensation)
Storage Environment: Temperature: -20~50℃; Humidity: 0~85% (No Condensation)
Standard Accessory: White and Black Calibration Board, Checking Green Board, Sample Holder, Φ4mm, Φ8mm, Φ15mm, Φ25.4mm Aperture, Power Adapter, USB Cable, User Guide, PC Software
Optional Accessory: Micro-printer, Transmissive Test Clamp Component
