Life: 10000 Cycle
Taper: Linear
Width: 9.5 mm
Length: 34.5 mm
Tolerance: 20 %
Resistance: 10 kOhms
Shaft Type: Knurled / Slotted
Orientation: Horizontal
With Switch: No Switch
Bushing Size: 7 mm
Element Type: Carbon
Power Rating: 500 mW
Shaft Length: 20 mm
Bushing Thread: M7
Mounting Style: PCB Mount
Shaft Diameter: 6 mm
Voltage Rating: 10 VDC, 50 VAC
Number of Gangs: 4 Gang
Bushing Material: Zinc Alloy
Number of Detents: Without Detent
Termination Style: Through Hole
Maximum Operating Temperature: + 75 C
Minimum Operating Temperature: - 10 C
