Max. Current Output: ±300mA continuous, ±420mA peak
Output Voltage: Maximum ±10V
Cell Connections: 2, 3, 4
Signal Acquisition: 3 independent acquisition links. Using adaptive filtering, amplification technology; adopting 16-bit, 10MSPS sampling rate ADC
CA Gain Bandwidth: 22MHz
Rising Time: 200V/μs
Electrometer Bandwidth: 10.5MHz (-3dB point)
Slot Pressure: ±10V, need to load 1.2k
Current Axis Bandwidth:
500R – 10MHz
5kR – 1.5MHz
50kR – 0.15MHz
Voltage Measurement:
Voltage range: ±0.02V, ±0.05V, ±0.09, ±0.023V, ±0.046V, ±2.28V, ±4.55V, ±10V
Resolution: 0.0015% of measuring range
Current Measurement
Current range: ±228pA to ±300mArms
Resolution: 0.0015% of measuring range, minimum 6.94fA
AC Impedance Method:
Frequency range: 0.1Hz – 3MHz
Amplitude: 5mVrms to 1Vrms
Accuracy: 1%
Cyclic Voltammetry:
Initial potential: -10V to +10V
High potential: -10V to +10V
Low potential: -10V to +10V
Scan rate: 0.001V/s to 10000V/s
Sampling interval: 0.001V to 0.064V
