Output Frequency
BeiDou: B1:1561.098MHz, B2:1207.14MHz, B3:1268.52MHz
GPS: L1:1575.42MHz, L2:1227.60MHz, L5:1176.45MHz
GLONASS: L1:1602.00MHz, L2:1246.00MHz
Galileo: E1:1575.42MHz, E5a:1176.45MHz, E5b:1207.14MHz
RDSS: L: 1618.25MHz, S: 2491.75MHz
Signal Scale
Channel number: 12/16 per frequency (optional)
Multipath number: 4/24 per frequency (optional)
Signal Quality
Spurious (max.): -40dBc
Harmonics (max.): -35dBc
Frequency stability: ≤5×10-11/sec, ≤±5×10-10/day
Signal Dynamic Performance
Relative velocity: 0 – 16,000m/s
Relative acceleration: 0 – 900m/s2
Relative jerk: 0 – 900m/s3
Phase Noise
-75dBc/Hz @100Hz
-80dBc/Hz @1kHz
-85dBc/Hz @10kHz
-90dBc/Hz @100kHz
Signal Control Level
Resolution: superior to 0.2dB
Absolute accuracy: superior to 0.2dB
Power Range: -150dBm to -60dBm
External Interface
1PPS/10MHz pulse signal input port: one BNC port
1PPS/10MHz pulse signal output port: one BNC port
RF output port: one Type-N port
Output Second Pluse Indicator
Output level: 1LVTTL
Rising edge stability: 0.1ns
Closed Loop Delay (Optional): Superior to 10ms
Inertial Navigation Simulation (Optional)
Data output rate: 400Hz/s (max.)
Output delay: ± 500ms
Unit signal accuracy: 0.1n mile/h
Adjustable step: 1μs
Power Supply: AC power 220V±20V, 200W
Dimension: 484.1(W) × 175(H) × 482.6(D)mm
