Width: 2.4 mm
Height: 0.85 mm
Length: 3 mm
Fall Time: 95 ns
Rise Time: 30 ns
Technology: Si
Unit Weight: 241.467 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 P-Channel
Qg - Gate Charge: 62 nC
Number of Channels: 1 Channel
Transistor Polarity: P-Channel
Pd - Power Dissipation: 2 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 20 ns
Typical Turn-Off Delay Time: 140 ns
Id - Continuous Drain Current: 39 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 15 S
Rds On - Drain-Source Resistance: 8 mOhms
Vds - Drain-Source Breakdown Voltage: 30 V
Vgs th - Gate-Source Threshold Voltage: 2.5 V
