Width: 4.4 mm
Height: 1.39 mm
Length: 8.7 mm
Function: NAND
Logic Type: CMOS
Unit Weight: 241 mg
Logic Family: 4000
Logic Function: NAND
Mounting Style: SMD/SMT
Number of Gates: 4 Gate
Supply Voltage - Max: 16 V
Supply Voltage - Min: 3 V
Number of Input Lines: 2 Input
Number of Output Lines: 1 Output
Propagation Delay Time: 90 ns
Low Level Output Current: 3 mA
Operating Supply Voltage: 3.3 V, 5 V, 9 V, 12 V, 15 V
High Level Output Current: - 1.2 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
