Channel: 4
Max. Frequency: 250 MHz
Max. Sample Rate: 2.5 GSa/s
Vertical Resolution :16 bits
Channel Skew
Range: -200 ns to +200 ns
Precision: ±200 ps
Channel-to channel Synchronization Accuracy: ±500 ps
Waveform Memory Depth: 64 Mpts/CH (standard), 128 Mpts/CH
(optional)
Frequency
Characteristics: Sine, Square, Ramp, Pulse, Arb, Harmonic, Noise (-3 dB),
Frequency Resolution, Frequency Accuracy, Clock Accuracy Aging
Sweep Start/Stop
Frequency Range
Sine: 1 μHz to 250 MHz
Square: 1 μHz to 120 MHz
Ramp 1: μHz to 2.5 MHz
Arb : 1 μHz to 100 MHz
Characteristics
Display: 10.1-inch touch screen, 1280x800 (screen area) 16:9
Power Supply
Input Voltage: AC 100 V to 240 V, 50 Hz/60 Hz
Consumption: 210 W (max.)
Fuse: 5 A, Class T, 250 V
Mechanical
Characteristics
Dimension: 358 mm (W) x 215 mm (H) x 122 mm (D)
Rack Mount Kit: 5 U
