Measurement
Compatibility: Optimap1, 2 & 3, TAMS, RoboTAMS
Field of View: 65 x 54mm
Measurement Focus: Dual Focus - Target Images and Surface
Spatial Resolution: 37 um/pixel
Measurement Techniques:
Phase Measurement Deflectometery
Optical Transfer Function
Line Deformation Analysis
Surface Imaging
Measurement Time: 10 Seconds
Topographical Output:
Curvature Map
Altitude Map
Filter Options
Wavescan Band Filtering
User Definable ISO GPS
High Pass, Low Pass, Band Pass
Profile Analysis: Yes
Measurement Parameters: K, Ka, Kb, Kc, Kd, Ke, KLW, KSW, T, Ta, Tb, Tc, Td, Te, TLW, TSW, Q, H, S, W, D, C, RaX, RaY, Sa, Rsm
Hardware
Processor: Intel i7 Gen 5
Memory: 256 GB
Battery: Rechargeable Lithium ion 12000mAh
Typical Use/Charge: 3 - 4 hours / charge
Camera: 3.2 MP- dual Focus
Output Data: Maps/CSV/Results database
Data Transfer/Speed: SD Card - 12.5 MBs
Display: 10.1 Capacitive Touch 1280 x 800
Dimensions: 233mm (H) x 314mm (H) x 235mm (D)
Carry options: 6 Point harness anchors
Fixture: Removable Measurement Base
Optional Extra: Wet paint measurement Base Customisable jigs and fixtures
Weight: 3.5Kg
Interface
HMI Interface: Optimap 3 GUI- 10 point touch
SPC Integration: Yes
Connectivity: LAN USB
