Width: 5 mm
Height: 1.45 mm
Length: 5.4 mm
Fall Time: 11 ns
Rise Time: 17 ns
Technology: Si
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 77 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 138 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 22 ns
Typical Turn-Off Delay Time: 40 ns
Id - Continuous Drain Current: 75 A
Maximum Operating Temperature: + 175 C
Forward Transconductance - Min: 40 S
Rds On - Drain-Source Resistance: 4.8 mOhms
Vds - Drain-Source Breakdown Voltage: 40 V
Vgs th - Gate-Source Threshold Voltage: 2.5 V
