Pressure test
Output voltage (KV): AC: 0.05-5.00 DC: 0.05-6.00
Test accuracy: ±(2.0% setting +2V)
output precision: ±(2.0% setting +5V) no load
Test current (mA): AC: 0.001mA-10mA DC: 0.1uA-5mA
Test accuracy/ Setting error: ±(2.0% reading + 5 digits)
Arc Detection
Current measurement range: 1mA-20mA
testing time: 0.1S-999.9S
Output frequency: 50Hz/60Hz
Input characteristics: 115V/230V±10% 50Hz/60Hz
test alarm: Buzzer, LCD display, FAIL indicator
keyboard lock: Independent keyboard lock key
screen size: 5 inch TFT LCD
Communication Interface: HANDLER, RS232, RS485, USBDRV (computer interface), USBHOST (U disk interface)
Voltage rise time: 0.1S-999.9S
Test time setting (AC/DC): 0.2S-999.9S
Voltage fall time: 0.1S-999.9S
waiting time: 0.2S-999.9S
storage: 16M flash, each file can store 50 test steps
weight: 15KG
Accessories: Test lead, ground lead, power lead，Cut connector DB9
Optional accessories: 16g U Disk (Including PC Software), RS232 To USB Cable, USB To Square Port Cable
