Measurement functions
Measurement parameters: Main: L/C/R/Z, Sub: D/Q/θ/X /ESR
Basic accuracy: 0.002
Test speed: Fast: 20, Medium: 10, Slow: 3 (times/second)
Test terminal configuration: Five terminals
Equivalent circuit: Series, parallel
Range mode: Auto, hold
Trigger mode: Internal, external
Calibration function: Open/short clear
Display: Large white backlight LCD
Tolerance limit: 1%, 5%, 10%, 20%
Test signal
Test frequency: 100Hz, 120Hz, 1kHz, 10kHz
Output impedance: 30Ω , 100Ω
Test level: 0.1Vrms, 0.3Vrms, 1.0Vrms
Measurement display range
|Z|, R, X, ESR: 0.0001Ω- 99.999MΩ
C: 0.01pF-19999μ F
L: 0.01µH-99999H
D: 0.0001-9.9999
θ(Deg): -179.9° – 179.9°
θ(Rad): -3.14159 – 3.14159
Q: 0.0001 – 999.9
Δ%: -19.9998
Comparators: Fixed percentage 5-level sorting and alarm
General specifications
Operating temperature, humidity: Temperature 0°C~40°C
humidity ≤90%RH
Power requirements: 99V~242V
Power consumption: ≤ 20VA
Dimensions (W×H×D): 307*309*120mm
Weight: About3.5kg
Accessories: Power cord, four-terminal Kelvin test lead, bridge test clip
