Resistance Measurement
Measuring Range: 10μΩ～200KΩ
Resistance Range: Basic Accuracy 0.05%
Number Of Scanning Paths: 16 Way
Maximum Test Current: 500mA
Display
Display: 24 Bit Color, Resolution 480 * 272 True Color IPS LCD
Reading Digit: Four And A Half Digit Display
Measurement Function
Resistance Measurement Time:
Fast Speed: 40 Times / S
Medium Speed: 20 Times / S
Slow Speed: 12 Times / S
Test Side Configuration: Four Terminal
Measurement Mode: Sequential Scanning
Save Test Parameters: 5 Groups
Temperature Measurement
Measurement Parameters: PT1000: Accuracy 0.1 ℃
Display Range: -10℃-99.9℃
Comparator
Signal Output:HI/PASS/LO
News Ring: Pass / Fail / Close
Limit Setting Mode: Absolute Value Upper / Lower Limit; Percentage Upper / Lower Limit + Nominal Value
Other Parameters
Interface: USB HOST/USB DEVICE/RS232/HANDLER/RS485
Working Environment: Temperature 0 ℃～ 40 ℃ Humidity < 80% RH
Dimension: 361×107×264mm
Weight: Net Weight About 4kg
Accessories: Four Terminal Kelvin Test Clip, Temperature Probe, USB / 232 Communication Cable, Plug-In Terminal, Power Line
