Test Resistance Range: 0.01mΩ- 200.0KΩ
Test Accuracy:
500mΩ Range 0.1% ± 3 Words,
5Ω, 50Ω, 500Ω, 5KΩ Range 0 . 1 % ± 2 Words,
50KΩ Range 0 . 1% ± 3 words,
Test Current: 100mA 10mA1mA 100uA10uA
Test The Range: 500mΩ 5Ω 50Ω 500Ω 5kΩ 50kΩ
Resolution: 10 UΩ 10 0 UΩ 1 MΩ 10 MΩ 100mΩ 1Ω 1 0Ω 1 00
Speed:
Slow 3 Times Per Second
Fast 10 Times/Sec
Measuring Mode: Automatic, Hold
Screen: 0.8 Inch 4 Digit Tube
Calibration: Short-Circuit Zero At Full Scale
Messages: Pass, Pass, Fail
Test Side: Four-Terminal Testing
Comparator Sorting:
Pass Display IN
(PASS) Under Ultra-Non-Conforming Display LO (FA IL)
On Ultra-Non-Conforming Display HI (FAIL)
Humidity: 0℃- 40℃，≦75%RH
Power Supply: 100V-121 V，198V242V，47.5 -63Hz
Fuse Specifications: 0.5A 250V 1A 110V SLOW MELT
Power Consumption: ≦15VA
Dimensions: 280mm×97mm×217mm
Annex: RK0000 POWER CORD, RK26004A QUAD
End Test Fixture
Weight: 2.2kg
