Width: 6 mm (0.236 in)
Height: 10 mm (0.394 in)
Length: 11.5 mm (0.453 in)
Industry: Industrial
Compliance: CAN/CSA; EAC; IEC; REACH; RoHS; UL
Efficiency: 82%
Unit Weight: 1.400 g
Output Power: 500 mW
Input Voltage: 10.8 V to 13.2 V
Mounting Style: Through Hole
Isolation Voltage: 1 kV
Number of Outputs: 1 Output
Input Voltage - Max: 13.2 V
Input Voltage - Min: 10.8 V
Input Voltage, Nominal: 12 V
Output Current-Channel 1: 100 mA
Output Voltage-Channel 1: 5 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
