Width: 7.05 mm (0.278 in)
Height: 10.2 mm (0.402 in)
Length: 19.65 mm (0.774 in)
Industry: Industrial
Compliance: CSA/CAN; EAC; IEC; REACH; RoHS; UL
Efficiency: 75%
Unit Weight: 2.700 g
Output Power: 1 W
Input Voltage: 21.6 V to 26.4 V
Mounting Style: Through Hole
Isolation Voltage: 4 kV
Number of Outputs: 1 Output
Input Voltage - Max: 26.4 V
Input Voltage - Min: 21.6 V
Input Voltage, Nominal: 24 V
Output Current-Channel 1: 200 mA
Output Voltage-Channel 1: 5 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
