Width: 7.6 mm (0.299 in)
Height: 10.2 mm (0.402 in)
Length: 11.5 mm (0.453 in)
Industry: Industrial
Compliance: CAN; CB; EAC; IECEE; REACH; RoHS; UL
Efficiency: 89%
Unit Weight: 2.200 g
Output Power: 3 W
Input Voltage: 10.8 V to 13.2 V
Mounting Style: Through Hole
Isolation Voltage: 2 kV
Number of Outputs: 1 Output
Input Voltage - Max: 13.2 V
Input Voltage - Min: 10.8 V
Input Voltage, Nominal: 12 V
Output Current-Channel 1: 250 mA
Output Voltage-Channel 1: 12 V
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 40 C
