Width: 7.05 mm (0.278 in)
Height: 10.2 mm (0.402 in)
Length: 19.65 mm (0.774 in)
Industry: Industrial
Compliance: CB; CAN/CSA; EAC; IEC; REACH; RoHS; UL
Efficiency: 80%
Unit Weight: 2.700 g
Output Power: 1 W
Input Voltage: 13.5 V to 16.5 V
Mounting Style: Through Hole
Isolation Voltage: 6.4 kV
Number of Outputs: 2 Output
Input Voltage - Max: 16.5 V
Input Voltage - Min: 13.5 V
Input Voltage, Nominal: 15 V
Output Current-Channel 1: 42 mA
Output Current-Channel 2: 42 mA
Output Voltage-Channel 1: 12 V
Output Voltage-Channel 2: - 12 V
Maximum Operating Temperature: + 90 C
Minimum Operating Temperature: - 40 C
