Width: 9.8 mm (0.386 in)
Height: 12.5 mm (0.492 in)
Length: 19.5 mm (0.768 in)
Industry: Industrial
Compliance: CAN/CSA; EAC; IEC; RoHS; UL
Efficiency: 75%
Unit Weight: 4.300 g
Output Power: 1 W
Input Voltage: 10.8 V to 13.2 V
Mounting Style: Through Hole
Isolation Voltage: 6.4 kV
Number of Outputs: 2 Output
Input Voltage - Max: 13.2 V
Input Voltage - Min: 10.8 V
Input Voltage, Nominal: 12 V
Output Current-Channel 1: 41 mA
Output Current-Channel 2: 41 mA
Output Voltage-Channel 1: 12 V
Output Voltage-Channel 2: - 12 V
Maximum Operating Temperature: + 90 C
Minimum Operating Temperature: - 40 C
