Nominal Force (KN): 2500
Stroke of Nominal Force (mm): 14
Stroke of Sliding Block (mm): 200
Number of Strokers (times/min): 28
Closed Height (mm): 430
Closed Height Adjustment (mm): 130
Distance From Slider Block Centre To the Frame (mm): 390
Length Between Columns (mm): 700
Hole Size for Die Handle:
+ Diameter (mm): 100
+ Depth (mm): 170
Size Of Worktable:
+ Left - right (mm): 1500
+ Front - Back (mm): 900
Blanking Hole Diameter (mm): 250
Table Plate Thickness (mm): 150
The Maximum Tilt Angle (°): -
Dimensions:
+ Left - right (mm): 2340
+ Front - Back (mm): 2675
+ Height (mm): 3850
Power (KW): 22
