Thermal Imaging Parameters
Detector Type: VOx uncooled focal plane detector
Spectral Band: 7~8.5μm
Thermal Sensitivity: ≤20mK(@25°C,F#1.0)
Infrared Resolution: 640×512
Pixel Pitch: 12μm
Lens Focal Length: 25mm
Focus Mode: Athermalized prime lens/Electric focusing
FOV: 17.5°×14°
IFOV: 0.48mrad
Palettes: Black-hot/White-hot/Rainbow/Other palettes optional (20 modes in total)
Visible Light Parameters
Sensor: 1/1.8" 4-megapixel CMOS image sensor
Maximum Image Resolution: 2688×1520
Lens Focal Length: 6.4mm~128mm
Focus Mode: Automatic/Manual/Semi-automatic
FOV: Horizontal: 59.6°~3.5°
Gas Parameters
Gas Type: Methane, ethane, propane, butane, pentane, hexane, heptane, octane, ethylene oxide, propylene oxide, ethylene, propylene, 1-butene, methanol, ethanol, butanol, ethylene glycol, isopropanol,etc
PTZ Parameters
Horizontal Range: 360° horizontal continuous rotation
Vertical Range: -90°~+90°
Number of Presets: 256
Scan Mode: Preset point/Patrol scan/Pattern scan/Area scanning/Linear scanning
Temperature Measurement Function
Measurement Range: -20℃~+550℃
Measurement Accuracy: ±2°C or ±2%
Temperature Analysis: Supports global, point, line, and area temperature measurement rules as well as alarm linkage.
PTZ Function
Fire Warning: Supports fire point detection.
Intelligent Video Taking: Video taking triggered upon alarms or network failures
Intelligent Alarm: Detects abnormalities, including network cable disconnections, IP address conflicts, memory errors, unauthorized access, and burn warnings, and triggers an alarm in response.
Intelligent Detection: Supports intelligent analysis of events such as tripwire intrusions and regional intrusions.
Alarm Linkage: Video taking/Image capture/Email/Linked PTZ/Alarm output
System Interface
Power Supply: 85V～260V AC/24V DC 3A (optional)
Communication Interface: 1 RJ45 10M/100M adaptive Ethernet port; 1-channel RS485 interface, supporting Pelco protocol.
Alarm Interface: 1-channel alarm input, 1-channel alarm output
General Specifications
Operating Temperature and Humidity: -40°C～+60°C; <90%RH
Ingress Protection Rating: IP68
Power Consumption: ≤100W (thermostat activated)
Dimensions: 436×296×406 mmWeight: 27kg
Explosion-proof Mark: Exd IIC T6 Gb/Ex tD A21 IP68 T80℃
