Thermal Imaging
Detector Type: 12μm uncooled infrared detector
Infrared Resolution: 256×192
Spectral Band: 7.5-14μm
Thermal Sensitivity (NETD): ＜40mK (25°C,F1.0)
Frame Rate: 25Hz
Lens Focal Length: 3.2mm
FOV: 56°×42°
Spatial Resolution (IFOV): 3.75mrad
Focusing Mode: Fixed focus
Minimum Imaging Distance: 0.3m
Measurement Range: -20°C~+150°C, 100°C~550°C
Measurement Accuracy: ±2ºC or ±2% of readings, whichever is greater
Imaging Display
Palettes: 7
Image Mode: Infrared
Temperature Width Stretch: Auto
Measurement and Analysis
App Analysis Function: Central temperature point/Highest temperature point/Lowest temperature point, 1 preset analysis template (support 3 custom points, 3 custom lines, and 3 custom frames)
System Functions
Communication Protocol: Wi-Fi, USB, Bluetooth
Remote Access and Control: Connection to smart devices via Wi-Fi, up to 8m away
Others
Battery: 1050mAh
Charging Mode: USB Type-C
Battery Life: About 2h
Tripod Socket: UNC 1/4-20 interface for tripod
Operating Temperature: -10°C~+50°C
Operating Humidity: 10%~90% (non-condensing)
Storage Temperature: -20°C~+60°C
Ingress Protection Rating: IP54
Shock and Vibration: Shock: 25g (IEC 60068-2-27); vibration: 2.5g (IEC60068-2-6)
Weight and Dimensions: About 132g, 135.6×41×29.1mm
Packing List: Thermal camera, USB cable
