Thermal Imaging Parameters
Detector: Uncooled VOx detector
Infrared Resolution: 384×288
Pixel pitch: 17μm
Spectral Band: 8μm~14μm
Thermal Sensitivity (NETD): <50mK
Temperature Measurement Function
Measurement Range: -20℃~+150℃,0℃~550℃
Measurement Accuracy: ±2°C or ±2% of readings, whichever is greater.
Temperature Measurement Correction: Reflected temperature, ambient temperature, atmospheric transmissivity, object emissivity, distance
Measurement Tool: Settings of measurement rules for a total of 12 points, lines, and areas Supports isotherm setting
Temperature Width Stretch: Support temperature width stretch
Image and Video
Frame Rate: 50Hz
Palettes: 18 color palettes including black-hot, white-hot, iron red, rainbow, etc.
Video Standards: H.264, H.265
Thermal Image Capture: Support thermal image capture and secondary analysis
Mirror Image: Horizontal/Vertical/Diagonal
Digital Zoom: 1.0~8.0 continuous zoom (step size: 0.1)
System Interface
Communication interface: RJ45，supporting Gigabit network and customized RS485 for Pecol-D protocol.
Video Interface: 1-channel analog video
Alarm Interface: 1-channel alarm output (optional)
Network Protocol: TCP, UDP, ICMP, DHCP, RTSP
Interface Protocol: ONVIF, GB28181
Device Specifications
Operating Temperature: -20℃~+60℃
Power supply mode: 10~36V DC, POE
Typical Power Consumption: 3W
Dimensions: 55mm×55mm×110mm
Weight: About 430g
