Metrological parameters
Maximum capacity [Max]: 600 g
Minimum load: 500mg
Readability [d]: 10 mg
Verification unit [e]: 10 mg
Tare range: - 600 g
Standard repeatability [5% Max]: 0.5 mg
Standard repeatability [Max]: 1 mg
Standard minimum weight (USP): 1 g
Standard minimum weight (U=1%, k=2): 0.1 g
Linearity: ±20 g
Stabilization time: 1.5 s
Adjustment: internal (automatic)
OIML Class: II
Physical parameters
Leveling system: manual
Display: LCD (backlit)
Delivery components: Balance, weighing pan, weighing pan shield,
grounding bumper ×1, bumper ×3, power supply.
Weighing pan dimensions: 128×128 mm
Net weight: 3.9 kg
Gross weight: 5 kg
Protection class: IP 43
Communication interface
Communication interface: 2×RS232¹, USBA, USBB, WiFi® (option)
Electrical parameters: Power supply
Adapter: 100 – 240V AC
50/60Hz 0.6A; 12V DC 1.2A
Balance: 12 – 15V DC
0.4A max
Power consumption: 4 W
Environmental conditions
Operating temperature: +10 — +40 °C
Relative humidity: 40% — 80%
