Number of sources in storage holder: up to 6
(241-Am, 137-Cs, 60-Co, etc. available on customer request)
Maximum gamma source activity (137Cs): up to 9.6 × 10¹³ Bq
Range of kerma in the air, 137Cs: 0.2 µGy/h – 22.2 Gy/h
Dose equivalent rate range, 137Cs: 0.2 µSv/h – 26.5 Sv/h
Exposure rate range, 137Cs: 24 µR/h – 2530 R/h
Accuracy of reference radiation field: up to ±2.5%
Beam axis above floor level: 1500 mm
Collimator channel outlet diameter: Ø60 mm or Ø90 mm
Collimator channel inlet diameter: 150 mm
Equivalent radiation dose rate at a distance of 1 m from the irradiator, no more than: 0.5 µSv/h
Operating distance range: 500 – 7000 mm
Positioning accuracy: ±0.15%
Discrete setting and indication of the working distance: 0.01 mm
Trolley movement speed, variable: 0.5 mm/s – 0.5 m/s
Range of the trolley vertical movement (Y axis): ±200 mm
Rotation axis: 360° (with 15° step)
Mass of accessory kits for irradiators and linear positioning system, not more than: 150 kg
Operating mode establishment time, not more than: 1 min
System continuous operation time, not less than: 24 h
