Detector: energy compensated silicon PIN diode
Energy range of the measures of photon radiation: 15 keV - 20 MeV
Personal dose equivalent rate (PDER) of continuous photon radiation measurement range: 1.0 μSv/h - 10 Sv/h
Average personal dose equivalent rate (PDER) of pulsed photon radiation measurement range: 10 mSv/h - 10 Sv/h
Personal dose equivalent (PDE) of photon radiation measurement range: 1.0 μSv - 20 Sv
Personal dose equivalent rate (PDER) of photon radiation indication range: 0.01 μSv/h - 10 Sv/h
Personal dose equivalent (PDE) of photon radiation indication range: 0.01 μSv - 20 Sv
Accuracy of continuous photon radiation PDER measurement: ±15 %
Accuracy of pulsed photon radiation average PDER measurement: ±15 %
Accuracy of photon radiation PDE measurement: ±15 %
Energy response relative to 0.662 MeV (137Cs):
±15 % for energy range 15 keV - 7 MeV
±40 % for energy range 7 MeV - 20 MeV
Thresholds: 2 for PDE and 2 for PDER
Threshold setting range:
for PDER: 1 μSv/h - 10 Sv/h
for PDE: 1 μSV - 20 Sv
Operation mode setup time, no more: 20 s
Data recording: 10 000 events
Alarm Type: audible, visual, vibration
PC communication: USB, RF
Dimensions: 85 x 57 x 21 mm
Weight: up to 95 g
Radiation resistance, at least: 100 Gy
Ingress protection: IP67
Drop test on concrete floor: 1.5 m
Mean recovery time: 1 h
Mean service lifetime: 10 years
Mean time between failures, no less than: 20 000 h
Atmospheric pressure: from 84 to 106.7 kPa
Operating temperature: -20 °С up to 50 °С
Humidity: up to 95 % at 40 °С
Resistance to decontamination solutions:
Solution № 1: NaOH 30 - 40 g/l, KMnO4 2 - 5 g/l
Solution № 2: H2C2O4 10 - 30 g/l, HNO3 1 g/l
Power source: AAA (LR03) battery or NiMH battery
Battery operating time, at least: 2 200 h on condition:
PDER up to 0.25 μSv/h
backlight usage up to 20 min/day
alarm duration up to 1 min/day
