Gender: Jack (Socket)
Polarity: Standard
Impedance: 50 Ohms
RF Series: SMA
Body Style: Screw On
Cable Type: RG-188, 316, KX22A
Body Finish: Gold
Orientation: Straight
Unit Weight: 5 g
REACH - SVHC: Details
Body Material: Stainless Steel
Mating Cycles: 500
Mounting Style: Cable Mount / Free Hanging
Voltage Rating: 250 V
Contact Plating: Gold
Contact Material: Beryllium Copper
Maximum Frequency: 12.4 GHz
Termination Style: Crimp
Insulation Resistance: 5 GOhms
Maximum Operating Temperature: + 165 C
Minimum Operating Temperature: - 65 C
