Carbon Dioxide Sensor Type: Solid-state Infrared
Accuracy - Carbon Dioxide: Accuracy (for 0-50%, 0-100% range): ± 1% of reading, or ± 0.2% (whichever is greater), Accuracy (for 0-10%, 0-20% range): ± 1% of reading or ± 0.1% CO2 (whichever is greater, Accuracy (for 0-2000
CO2 Minimum Detection Limit: 0.1% (0-50% and 0-100% ranges), 0.01% (0-2.5%, 0-10% and 0-20% ranges), 10 ppm (0-5000ppm)
CO2 Calibration Controls: Potentiometer SPAN adjustment for CO2.
CO2 Calibration Frequency: Every 12 months; calibration gas recommended.
Analog Output: 0 to 1Vdc, 0-5Vdc, 0-10 Vdc, or 4-20mA, linear, proportional to CO2 concentration
Resolution: 0.1% CO2 for 0 to 30, 0-50, and 0 to 100% ranges (0.01% CO for 0 to 2.5%, 0 to 10%, or 0 to 20% ranges) (0.001% CO2 for 0 to 1%)
Accuracy: +/-1% of reading, or 0.2% CO2 for 0-100% range
Drift: less than 0.4% per year
Oxygen Sensor Type: Infrared (NDIR); non-depleting with no moving parts
Response Time: 20 seconds to T95
O2 Sensor Lifetime: Theoretically unlimited (average 8 years)
Sample Connection: Front panel fitting with luer connection for disposable filter, plastic splitter; 1/16 to 1/8 ID tubing; (optional) Swaglok inlet
Sample Method: Pump (Optional)
Sample Pump: Optional; internal, with on-off switch on front panel, draws about 5 cc/sec
Pump Timing: (Optional) 2-mode pump switch (timed, or continuous); (optional) cycling pump with on/off timer
Minimum Sample Required: 15cc
Sampling Assembly: Inlet fitting
Instrument Calibration: With standard calibration gas (available from Quantek if needed); SPAN adjustment on rear panel ZERO potentiometer located on rear panel
Exhaust port: Vents to air (optional connectible exhaust for capturing exhaust)
Power Supply: Internationally compatible charger or power supply, 100/240V (50/60Hz) to 12V
Backup Power: Optional 12V internal battery pack
Battery Operation: Optional, with internal rechargeable 12 Vdc battery
Input Voltage: 100-240V, 50-60Hz
Battery Life: 8-12 hours before recharging
Measures: O2, CO2: CO2
Form Factor: Benchtop
Size: 10 in. x 4 in. x 10.5 in. (25.4 cm x 10.6 cm x 26.67 cm)
Weight: 7 lbs. (3.18 kg)
Standards: CE, RoHS
Included Consumables: Plastic syringes for sample collection, 5 spare internal moisture blocking filters
Options: Internal pump, cycling-enabled pump, 0-5Vdc analog output, internal relay/control board to activate external audible alarm, buzzer, or contact closure.
Included Documentation: Owners manual (includes operating instructions with detailed calibration instructions, calibration certficate, precautions), NIST calibration certificate
Origin of Goods: Our goods are manufactured in the U.S.A.
