Gain: 31.7 dB
Technology: Si
Unit Weight: 3.410 g
Mounting Style: SMD/SMT
Test Frequency: 2 GHz
Development Kit: TQM879006A-PCB
Input Return Loss: 21 dB
NF - Noise Figure: 1.5 dB
Moisture Sensitive: Yes
Number of Channels: 1 Channel
Operating Frequency: 1.4 GHz to 2.7 GHz
Pd - Power Dissipation: 250 mW
Operating Supply Current: 174 mA
Operating Supply Voltage: 5 V
P1dB - Compression Point: 24.5 dBm
OIP3 - Third Order Intercept: 43 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
