Gain: 18 dB
Technology: Si
Mounting Style: SMD/SMT
Test Frequency: 2.6 GHz
Development Kit: QPA9143EVB-01
Input Return Loss: 8.5 dB
NF - Noise Figure: 1.9 dB
Moisture Sensitive: Yes
Number of Channels: 1 Channel
Operating Frequency: 2.3 GHz to 3.8 GHz
Pd - Power Dissipation: 700 mW
Operating Supply Current: 70 mA
Operating Supply Voltage: 5 V
P1dB - Compression Point: 19.5 dBm
OIP3 - Third Order Intercept: 35 dBm
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
