Technology: Si
IF Frequency: DC to 3 GHz
LO Frequency: 6.5 GHz to 10.5 GHz
RF Frequency: 13 GHz to 21 GHz
Mounting Style: SMD/SMT
NF - Noise Figure: 8.5 dB
Supply Voltage - Max: 5 V
Supply Voltage - Min: 2 V
Conversion Loss - Max: 8.5 dB
Pd - Power Dissipation: 670 mW
Operating Supply Current: 32 mA
Operating Supply Voltage: 3 V
P1dB - Compression Point: 4 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 55 C
