Direct access to our certified experts
Gain: 2 dBi, 6 dBi
VSWR: 2
Style: T-Bar Flex
Width: 50 mm
Height: 27 mm
Length: 100 mm
Impedance: 50 Ohms
Cable Type: 100 mm RF1.13 x 2
Application: Wireless Applications, ISM Applications, DSRC, Routers, Gateways, Security, Transportation, M2M, IoT Devices
Cable Length: 100 mm
Polarization: Linear
Power Rating: 3 W
Mounting Style: Adhesive Mount
Number of Bands: 2 Band
Center Frequency: 2.45 GHz, 5.5 GHz
Mechanical Style: PCB Trace
Maximum Frequency: 5.9 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM, U-NII
Antenna Connector Type: U.FL
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), DSRC
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
