Gain: 3.5 dBi, 6.5 dBi
VSWR: 2:1
Style: Radome
Length: 172.974 mm
IP Rating: IP67
Impedance: 50 Ohms
Application: Access Points, Base Stations, Public Safety, Repeaters, Small Cell
Unit Weight: 127.639 g
Polarization: Vertical
Power Rating: 20 W
Mounting Style: Bracket Mount
Electrical Type: Dipole
Number of Bands: 2 Band
Center Frequency: 2.45 GHz, 5.5 GHz
Mechanical Style: Collinear
Maximum Frequency: 5.9 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM, U-NII
Antenna Connector Type: N Male
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE)
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
