Gain: 2.5 dBi
Style: T-Bar
Width: 30 mm
Length: 116 mm
Impedance: 50 Ohms
Cable Type: 100 mm RF1.13
Application: Satellite Tracking, ISM Applications, Wireless Applications
Polarization: Vertical
Power Rating: 3 W
Mounting Style: Adhesive Mount
Electrical Type: Monopole
Number of Bands: 2 Band
Center Frequency: 868 MHz, 915 MHz, 2.4 GHz, 5 GHz
Mechanical Style: PCB Trace
Maximum Frequency: 2.69 GHz
Minimum Frequency: 617 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM, RFID, U-NII
Antenna Connector Type: U.FL
Protocol - GPS, GLONASS: GNSS
Protocol - WiFi - 802.11: 802.11, LoRaWAN, SigFox, WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G/5G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, WCDMA
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
