Gain: 0.8 dBi
Style: T-Bar Flex
Width: 15 mm
Height: 0.1 mm
Length: 75 mm
Impedance: 50 Ohms
Cable Type: 100 mm RF1.13
Technology: ISM
Application: Devices with ISM 868 MHz/915 MHz Radios, Instrumentation, M2M, IoT, Metering and Industry Automation
Unit Weight: 740 mg
Cable Length: 100 mm
Polarization: Linear
Power Rating: 2 W
Mounting Style: Adhesive Mount
Number of Bands: 2 Band
Center Frequency: 868 MHz, 915 MHz
Mechanical Style: PCB Trace
Maximum Frequency: 928 MHz
Minimum Frequency: 863 MHz
Termination Style: Connector
Protocol - Sub GHz: ISM, RFID
Antenna Connector Type: U.FL Female
Protocol - WiFi - 802.11: LoRaWAN, SigFox
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE)
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
