Gain: 1.4 dBi, 2.7 dBi, 3.5 dBi
VSWR: 2:1, 2.5:1
Style: Cone
Length: 77.2 mm
Diameter: 40.9 mm
IP Rating: IP67
Impedance: 50 Ohms
Cable Type: 700 mm RG174
Application: LTE Radio Systems, Logistics, Metering, Public Safety, Transportation, Vehicular Use
Unit Weight: 117.600 g
Cable Length: 700 mm
Polarization: Vertical
Power Rating: 10 W
Mounting Style: Direct / Permanent Mount
Electrical Type: Monopole
Number of Bands: 3 Band
Center Frequency: 750 MHz, 850 MHz, 868 MHz, 900 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2500 MHz
Mechanical Style: Module
Ground Plane Size: 12 in x 12 in
Maximum Frequency: 2.7 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: SMA Male
Protocol - WiFi - 802.11: 802.11, WLAN, WiMAX
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, WCDMA
