FREQUENCY
- Frequency Range: From 150 kHz to 3 GHz
- Center Frequency: 0.1 MHz
Accuracy: Within ±50 kHz (frequency span: from 0.3 GHz to 2.6GHz, 20 ±5 °C)
- Frequency Span: From 1 MHz to 3 GHz
Accuracy: Within ±3 % (frequency span: from 0.3 GHz to 2.6 GHz, 20 ±5 °C)
- Resolution Bandwidth: 30 kHz, 100 kHz, 300 kHz, 1 MHz
- SSB Phase Noise: -85 dBc/Hz (typical 500 kHz offset, resolution bandwidth: 30 kHz, Sweep time: 1,5 s Span: 1 MHz@1GHz)
- Inherit Spurious Response: Less than -45 dBc @ -40 dBm Reference level (typical less than -50 dBc)
AMPLITUDE
- Reference Level: From +20 to -40 dBm
Accuracy: Within ±2 dB (1 GHz); SPAN: 5 MHz
Units dBm, dBV, dBµV
- Average Noise: Level ≤ -100 dBm (typical, center frequency: 1 GHz resolution bandwidth: 30 kHz)
- Frequency Characteristic: Within ±3 dB @ 300 MHz ~ 2.6 GHz
Within ±6 dB @ 80 ~ 300 MHz, 2.6 ~ 3 GHz
- Input
Impedance: 50 Ω
Input VSWR: Less than 2.0 @ input attenuation ≥10 dB
Input damage level: +30 dB (CW average power), 25 VDC
Input connector: N connector
SWEEP
-Sweep time: From 300 ms to 8,4 s, auto (not adjustable)
Accuracy: ± 2% (frequency span: full span)
Display: 640x480 pixels RGB color LCD
Communication interface: RS-232C (Sub-D female 9 pins)
USB connector (USB Host/Device full speed supported)
VGA Output: Sub-D female 15 pins
Power: AC 100 ~ 250 V, 50/60 Hz
Dimensions: 296 (W.) x 105 (H.) x 105 (D.) mm
Weight: Approx. 2.2 kg
