DIGITAL STANDARDS:DVB-T, DVB-T2, DVB-T2 lite
DVB-T2-MI (Gateway to modulator)
DVB-C, DVB-C2
DVB-S, DVB-S2, DVB-S2 multistream
ISDB-T/Tb
DSS, ACM/VCM/CCM
DAB, DAB+
MPEG-TS
AUDIO CODECS:MPEG-1, MPEG-2, AAC, HE-AAC, Dolby Digital, Dolby Digital Plus
VIDEO CODECS:MPEG-2, MPEG-4 / H.264, HEVC / H.265
INPUTS AND OUTPUTS:
Universal RF connector 75 Ω
ASI-TS input and output
IPTV input UDP/RTP RJ45 Ethernet 1 Gbps
HDMI output
IP input for remote control
Analogue Video/Audio input
Common Interface module slot
1 pps input
2xUSB for data tranferring and GPS module
SPECTRUM ANALYZER:
Frequency Margin:From 5 - 1000 MHz (Terrestrial)
From 250 - 2500 MHz (Satellite)
Measurement range:From 10 - 130 dBµV
Span:Full / 500 / 200 / 100 / 50 / 20 / 10 MHz
Resolution bandwidths:2 kHz (terrestrial)
10, 20, 30, 40, 100, 200 kHz
1 MHz
MEASUREMENT MODE (please refer to STANDARDS section)
Frequency Margin:From 5 - 1000 MHz (Terrestrial)
From 250 - 2350 MHz (Satellite)
DVB-T COFDM :Power (35 to 115 dBμV), CBER, VBER, MER, C/N, Link margin
DVB-T2 Base and Lite COFDM: Power (35 to 115 dBμV), CBER, C/N, LBER, MER, Link Margin, BCH ESR, LDP iterations, Wrong packets
DVB-C QAM: Power (45 to 115 dBμV), BER, MER, C/N, Link margin
DVB-C2 COFDM: Power (45 to 115 dBμV), CBER, MER, C/N, LBER, BCH ESR, LDP iterations, wrong packets
PAL, SECAM and NTSC: M, N, B, G, I, D, K and L
FM radio :Level measurement
DVB-S QPSK: Power (35 to 115 dBμV), CBER, MER, C/N, Link Margin
DVB-S2 QPSK, 8PSK, 16/32APSK: Power (35 to 115 dBμV), CBER, LBER, MER, C/N, BCH ESR, Wrong packets, Link Margin
DSS QPSK :Power (35 to 115 dBμV), CBER, VBER, MER, C/N, Link margin
INTERNAL STORAGE:6 GB for measurement protocols, screenshots and transport stream recordings
PC CONNECTION (via ethernet interface):NetUpdate 4 (free software) + Free and automatic firmware updates
+ User customised channel plans + Measurement reports and screenshots
GENERAL:Hybrid operation: Touch screen (7”) or conventional keyboard
DiSEqC 2.x generator (DiSEqC 1.2 commands implemented)
dCSS / SCD 2 (EN50607) and SATCR/SCD (EN50494)
BATTERY:> 4 h (smart battery)
HARD CASE:Included
