Current: 1.2A / 2.4A max (chế độ Turbo ON).
Voltage: 20V
Power: 24W, 48W max
Protections:
Over Power Protection(OPP): 105%
Over Current Protection(OCP): 105%
Over Voltage Protection(OVP): 105%
Over Temp Protection(OTP): YES
* Constant Current Mode:
Range:
+ 0 ~ 0.12A/0.002mA
+ 0 ~ 1.5A/0.02mA
Accuracy: ± 0.01%
* Constant Resistance Mode:
Range:
+ 16.667Ω ~ 1000KΩ/1uS
+ 0.1200Ω ~ 16.667Ω/0.2778mΩ
Accuracy: ± 0.2%
* Constant Voltage Mode:
Range:
+ 0 ~ 2V/0.034mV
+0 ~ 20V0.34mV
Accuracy: ± 0.05%
* Constant Power Mode:
Range:
+ 0 ~ 2.4W/0.04mW
+ 0 ~ 24W/0.4mW
Accuracy: ± 0.5%
* Constant Current + Constant Voltage Mode:
Range Voltage : 20V/0.034mV
Range Current: 1.2A/0.02mA
Accuracy: ± 1.0%
Constant Power + Constant Voltage Mode:
Range Voltage: 20V/0.034mV
Range Power: 24W/0.4mW
Accuracy: ± 1.0%
Mode Turbo ON: max current 2.4A
Interface (optional) : GPIB, RS232, USB, LAN
Dimension: 143 x 108 x 412 mm
Weight: appr 3.7Kg
