Measuring range:0-100 degree
Measurement accuracy: ±10% or±1degree, the bigger one
Repeatability: ≤5%
Resolution: 0.1 degree
Pressure range: ≤0.1Mpa
Sensor material
Body: SUS316L(normal),
Titanium alloy (seawater version); Cable PUR
Power source: AC:85-500 VAC,DC:9-36 VDC
Output: 3 way 4-20 mA
Relay: Three-way relay, program setting response parameters and response values
Communication protocol: MODBUS RS485
Storage temp.: -15 to 50℃
Operating temp.: 0 to 45℃(No frozen)
Dimension
Sensor:Dia. 34mm* L 237mm
Transmitter:145*125*162mm(L*W*H)
Weight: Sensor:0.8KG,Transmitter:1.35KG
Class of protection: Sensor:IP68/NEMA6P;Transmitter:IP66/ NEMA4X
Cable length: Standard: 10M cable,Can be extended into 100M
